Half A Flower Burrs Crimped Wire Mesh Quarry Screen Is Easy Joining
Together To Use
Crimped Wire Mesh can be also known as the iron crimped mesh,
stainless steel crimped mesh, black iron crimped mesh according to
different materials. Crimped Wire Mesh is made in a variety of
materials through crimping mesh machine, a kind of universal wire
products with square or rectangular openings.
Crimped Wire Mesh Specification
1. Material: iron wire, black wire, stainless steel wire, copper
wire, etc.
2. Weaving type: pre-crimping before Weaving. In two-way separated
wave bending, locked bending, flat-topped curved, two-way bending,
one-way separated wave bending.
3. Crimped Wire Mesh Features:
Structure firm and durable
Good strength and economic cost.
High temperature resisting.
Corrosion resistance, acid resistance and alkali resistance.
4. Crimped Wire Mesh Applications
Used for mining, coal plants, construction, petrochemical industry,
construction machinery, etc.
1. We could make small samples for customer before the order
according to your request .
2. If client come to visit us ,we shall pick you up at beijing
airport ,arrange hotels,and send you return to the airport on time
.
3. We shall attach importance to your feedback to our products or
company .
When screens form part of the manufacturing process, the profits
will depend on the specification of the screens which must be
chosen to give optimum performance. The specification of the screen
best suited to the screening operation depends on:
The screen selected must achieve a compromise amongst these
factors.
When ordering screens the following technical aspects should be
taken into account :
Thickness of wire
Thick wire will last longer than thin wire, but will give a smaller
open area and will therefore pass less material per unit area.
Open Area
This is the most important factor in obtaining maximum output. The
larger the open area the less screen is wasted and the faster the
speed of screening. This open area factor must balanced against the
wire diameter to give adequate life
Mesh
The mesh refers to the number of openings per inch. The mesh is
counted by starting from the centre of one wire and counting the
number of opening to a point one inch away.
| Mesh/Inch | Wire Diameter(mm) | Aperture(mm) | Weight(kg/m2) |
| 1mesh | 4.06 | 21.34 | 8.24 |
| 1mesh | 3.25 | 22.15 | 5.5 |
| 1mesh | 2.64 | 22.76 | 3.5 |
| 1.5mesh | 2.34 | 14.6 | 4.11 |
| 2mesh | 2.64 | 10.06 | 8.98 |
| 2mesh | 2.34 | 10.36 | 5.48 |
| 2mesh | 1.63 | 11.07 | 2.62 |
| 3mesh | 2.64 | 5.67 | 11.5 |
| 3mesh | 2.2 | 6.27 | 7 |
| 3mesh | 1.63 | 6.84 | 4 |
| 4mesh | 2.64 | 3.55 | 14.5 |
| 4mesh | 2.2 | 4.15 | 9 |
| 4mesh | 1.63 | 4.72 | 5 |
| 5mesh | 1.63 | 3.45 | 7 |
| 5mesh | 1.22 | 3.89 | 4 |
| 6mesh | 1.22 | 3.04 | 4.5 |
| 6mesh | 0.91 | 3.31 | 2.6 |
| 7mesh | 1.22 | 2.47 | 5.6 |
| 8mesh | 1.22 | 1.95 | 6 |
| 8mesh | 0.91 | 2.26 | 3.3 |
| 8mesh | 0.81 | 2.36 | 2.6 |
| 10mesh | 0.91 | 1.63 | 4.2 |
| 10mesh | 0.81 | 2.16 | 3.3 |
| 12mesh | 0.71 | 1.41 | 3.1 |
| 14mesh | 0.56 | 1.25 | 2.2 |
| 16mesh | 0.46 | 1.03 | 1.8 |
| 18mesh | 0.46 | 0.95 | 2 |
