1-19mm Diameter Wire Rope Galvanized Steel Wire Rope Used Building
Protection
Galvanized Steel Wire Rope
Construction:6*7,6*12,6*19,6*37,7*7,7*19
Core: White cotton core.PP core,Jute core,steel core
Size:3mm-38mm
T/S:1570MPA,1770MPA,1960MPA,2170MPA
Length: 1000M/REEL,2000M/REEL, 200M/COIL,100M/COIL,300COIL
according customer requires
Material: high tensile carbon steel,hot dip galvanized wire, a 95%
zinc coating with the addition of 5% aluminum, stainless 304
Tensile: 1770 mpa
Coating: hot dip galvanized, dry
packing on plywood reel 2000m
Delivery: 30 days for a 20 feet container(20 tons).
Application: Aircraft, Auto, Hoisting, Lifting, Farming, Control,
Garden
| STEEL GRADE | CHEMICAL COMPOSITION(%) |
| C | Si | Mn | p | S |
| 60# | 60 | 20 | 53 | 10 | 9 |
Reference | Construction |
| Steel strand | 1x7, 1x19, 1x19S, 1*19W, 1*25Fi, 1*29Fi |
| Aircraft cable | 7x7, 7x19 |
| Traw fishing application | 6x19AW+FC, 6x19AS+FC
6x19+FC, 6X19+IWRC
6x37+FC, 6X37+IWRC
6*7+FC, 7*7, 6*24+7FC |
| Hoisting lifting applilcation | 7x7, 7*19, 6*19W+IWS
6*19+FC, 6X19+IWRC
6x37+FC, 6X37+IWRC
6*19S+FC, 6x19S+IWRC
6*19W+FC, 6*19W+IWRC
6*25FI+FC, 6*25FI+IWRC
6*29FI+FC, 6*29FI+IWRC
6*31WS+FC, 6*31WS+IWRC
6x36WS+FC, 6*36WS+IWRC |
| Combination rope for fishing | 3(1×19), 3(1×24), 6(1×19), 6(1×24), 6(1×7), etc. OEM |
| Non-rotating Steel wire rope | 18x7+FC, 18x7+IWS, 19x7 |
| Winch lifting application | 4X25Fi+PP, 4X26WS+PP, 4X31S+PP, 5X26WS+PP
6*19W+IWS, 6*19W+IWRC |
| Compacted wire rope:(fible core or steel core) |
| 6xK19S+FC, 6xK19S+IWRC, 6x25KFi, 6x25KFi, 6x29KFi, 6x29KFi,
6X26KWS, 6x31WS, 6X36WS |
| Material: high carbon steel rod #60, #70, #72A, #80, #82A, #82B |
| Strandard: GB, DIN, BS, EN, etc. |
Surface:
Galvanized, Ungalvanized, Stainless, PP/PVC/PE coated
Zinc Aluminum alloy (A 95% zinc coating with the addition of 5% aluminum) |
